Filtrine 107-16 Drinking Fountain
Wall-Mounted, Single Bowl
Filtrine’s Model 107-16 drinking water fountain features graceful, sleek lines inspired by Yamasaki’s architectural designs and selected by I.M. Pei for installation in the Louvre and the National Gallery of Art. Made in your choice of 16 gauge stainless steel or bronze, with 14 gauge support arms, the fountain features a seamless bowl with a welded rim, which is ground and polished to a finely tapered edge. Durable and beautiful, these fountains are available in a wide range of finishes and options including "Hands Free".
Select Your Configuration Options:
Specifications:
The Model 107-16 is a wall-mounted drinking water fountain. The 16” diameter 16 ga. round bowl has an integral drain. The hand-polished bronze finish comes in either #4 Satin (standard), or in #8 Mirror or Oil-Rubbed or Statuary Bronze. The hand-polished stainless steel drinking fountain can be finished in your choice of either #4 Satin (standard), or #8 Mirror. The copper/brass waterways are 100% lead-free—NO PLASTIC TUBING/CONNECTORS ARE USED.
Filtrine’s 107-16 fountain meets or exceeds ADA requirements for spout height, spout location, controls and clearances as specified in the Federal Register.
Details
Receptor: 16 ga, 16” diameter seamless bowl design with welded rim, ground and polished to a finely tapered edge with 1/32” radius.
Underbowl: Raised from support arm by 1/2” collar to provide an aesthetically pleasing profile.
Support Arm: 4-3/8” wide by 2-5/8” high — in 14 gauge. Overall fountain height 3-1/4”.
Mounting Plate: Made of a 1/4” steel plate, 15 1/2″W x 10 1/2″H or 19 1/2” high with the optional bottle filler, and a 3/8” steel tongue projecting into support arm.
Cover Plate: (Optional) Made of 16 ga stainless steel or bronze, 16″W x 3/8″D x 11″H (or 21” H with optional water bottle filler), and fits over mounting plate, secured by fountain arm.
Download CAD Drawings and BIM Models
Visit the Filtrine Model 107-16 CADdetails page to download CAD drawings and BIM models. Formats include: 2D DWG, DWF, DXF, GIF, PDF (CAD), VWX. 3D file formats include: RFA, SketchUp.
