Filtrine 107-14-HHL-VP High/High/Low Drinking Fountain
Wall-Mounted, Triple Bowl, Tamper Resistant
The vandal proof Filtrine Model 107-14-HHL is a high/high/low triple fountain with tamper proof features. Based on Filtrine’s popular 107-14-HL model, this model has an additional drinking bowl for more capacity making it particularly suited for high-traffic locations. Made in your choice of 16 gauge stainless steel or bronze, with 14 gauge support arms, the fountain features a bowl design with a 1/8" rolled edge and concealed seam. Durable and practical, these fountains are available in a wide range of finishes and options including "Hands Free".
Select Your Configuration Options:
Specifications:
The Model 107-14-HHL-VP is a vandal proof wall-mounted triple bowl drinking water fountain. The 14” diameter 16 ga. round bowls each have an integral drain. Low bubbler fountain height is 34-1/4”. The hand-polished bronze finish comes in either #4 Satin (standard), Oil-Rubbed or Statuary Bronze. The hand-polished stainless steel drinking fountain and cover plate can be finished in your choice of either #4 Satin (standard) or powder coat finish, RAL color match possible. The copper/brass waterways are 100% lead-free—NO PLASTIC TUBING/CONNECTORS ARE USED.
Filtrine’s 107-14-HHL-VP fountain meets or exceeds ADA requirements for spout height, spout location, controls and clearances as specified in the Federal Register.
Details
Receptor: 16 ga, 14” diameter seamless bowl design with welded rim, ground and polished to a finely tapered edge with 1/32” radius
Underbowl: Raised from support arm by 1/2” collar to provide an aesthetically pleasing profile
Support Arm: 4-3/8” wide by 2-5/8” high — in 14 gauge
Mounting Plate: 1/4” steel plate 15-1/2” high (20 1/2″ high w/optional bottle filler) for vertical strength, 47-1/2” wide with 3/8”steel tongue projecting into support arm for maximum horizontal stability
Cover Plate: 16 ga stainless steel or bronze, 48″W x 3/8″D x 16″H (21″H w/optional bottle filler), and fits over mounting plate, secured by fountain arm
Standard Features: Vandal proof 14 gauge stainless steel support arm, 16 gauge fountain bowl, mounted on 3/8″ steel mounting tongue above lower bowl. Soft touch button with set screw for security; matching bottom plate secured with “snake eye” screws. Cover plate to be fit over mounting plate
Related Models
Related Applications
Colleges & University Water Fountains
Colleges and universities are increasingly focused on reducing their environmental footprint. Filtrine supports these efforts with drinking fountains and bottle filling stations designed for long-term sustainability and performance. Units are available with both “Hands Free” and manual filler options to promote reusable bottle use and minimize single-use plastics. Engineered with immersion coil evaporators, Filtrine drinking water chillers deliver more chilled water with less energy, making them a smart, efficient choice for higher education facilities committed to responsible resource use.
Hotel & Retail Water Fountains
The ability to match any décor makes the durable, beautiful Filtrine drinking fountains/bottle filling stations a dramatic feature either indoors or outdoors. Filtrine’s drinking water equipment graces hotel lobbies and retail outlets across the US and overseas. Whether the building is modern or historic, the wide variety of models, materials and finishes including bronze, stainless steel and more, are popular with architects and engineers. Operations are a breeze with “Hands Free“, vandal proof, electric water cooler and access panel options.
Industrial Water Fountains
For extreme environments such as those found at oil & gas or heavy-duty manufacturing facilities, consider the Filtrine INDESTRUCT Model IM industrial electric water coolers. In addition to saving money by eliminating bottled water shipping and storage costs, they are sustainable and durable enough for any environment. Other models include high ambient Model IM-HA, and explosion-proof Model IM-XP. For information on “Hands Free” sensor activation, contact your local Filtrine Drinking Water Representative.
Religious
The wide variety of Filtrine drinking fountain and bottle filling station bronze finishes enhance many church, mosque or temple’s interior design. Filtrine’s unique solid bronze drinking fountains/bottle filling stations have long been sought by national religious institutions. Any Filtrine drinking fountain/bottle filling station can be made “Hands Free”. To deliver chilled fresh tasting purified water to multiple Filtrine drinking fountains/bottle filling stations, Filtrine remote chiller/purifiers are installed. They are hidden away behind the wall or in the ceiling.
Schools
School systems throughout the US have become concerned about lead in their buildings’ drinking water. Old pipes and untreated city water are the main issues. Filtrine has two ways for schools to remove lead from drinking water.
- Filtrine’s vandal proof drinking fountains, bottle filling stations and electric water coolers are popular because of their durability. Point of use drinking water chillers and purifiers can be added to drinking fountains and bottle filling stations to eliminate lead, organic tastes/odors, chlorine taste/odor and pathogens. Any Filtrine drinking fountain/bottle filling station can be made “Hands Free” to cut down on germ transmission.
- Filtrine’s point of entry water filtration system uses pre-filters, purifiers and optional UV sterilizers. It delivers lead-free water throughout the school building. Visit Point of Entry Water Filtration Explained for more information.
